Module Samples

Available modules can be ordered at the bottom of each product page. We ship to worldwide locations.

Flat rate shipping is available within the USA via USPS, and worldwide via DHL International Express.

BH678T, the lowest power Bluetooth module

  • BLE 4.2 module
  • With Toshiba TC35678 SoC, ARM Cortex M0 processor
  • 384KB ROM, 256KB flash, 192KB RAM
  • integrated high performance PCB trace antenna, 60 meter range
  • 3.6 mA peak current
  • Size: 14x16x1.9 mm;
  • Hybrid pins: 16 castellated pins for products needing limited GPIOs. Easy prototyping and easy production.
  • 24 additional LGA pins to access all GPIOs.
  • Certifications: Pending
  • $4.73 each at 1K pcs

BH661C, Dual Mode BLUETOOTH 4.2 MODULE

  • With Toshiba TC35661 SoC
  • HCI interface with a host MCU
  • BH661C-503: SPP and GATT profiles
  • BH661C-551: SPP and GATT profiles, secure connection
  • BH661C-006: WBS (WideBand Speech) profile
  • BH661C-203: V3.0 SPP, achieving 1.2 Mbps SPP throughput.
  • integrated chip antenna, 50 meter range
  • Size: 11x16.7x1.9 mm;
  • 24 castellated pins, easy prototyping, easy production
  • Certifications: FCC, Industrial Canada
  • $4.93 each at 1K pcs

BH676CP, THE LOWEST COST BLUETOOTH MODULE

  • BLE 4.1 module
  • With Toshiba TC35676 SoC, ARM TDMI-S processor
  • 256KB ROM, 256KB flash, 224KB RAM
  • integrated PCB trace antenna, 20 meter range
  • 6 mA peak current
  • Size: 11x17.7x1.9 mm;
  • 24 castellated pins, easy prototyping, easy production
  • Certifications: FCC, Industrial Canada
  • $2.99 each at 1K pcs

BH676T, Long Range BLUETOOTH MODULE

  • BLE 4.1 module
  • With Toshiba TC35676 SoC, ARM TDMI-S processor
  • 256KB ROM, 256KB flash, 224KB RAM
  • integrated high performance PCB trace antenna, 60 meter range
  • 6 mA peak current
  • Size: 15x25.3x2.0 mm;
  • 24 castellated pins, easy prototyping, easy production
  • $3.99 each at 1K pcs

WS662, WiFi and dual mode Bluetooth Module

  • Hosted/standalone WiFi+Bluetooth module with Toshiba TC35662
  • Bluetooth 4.0 EDR + BLE stacks embedded in mask ROM
  • IEEE 802.11 b/g/n embedded WiFi stacks for MCU host with an UART port for remote control application
  • An SDIO interface to Linux host processor with WiFi stacks for high speed data application
  • IEEE 802.11 security: WEP, WPA/WPA2 (TRIP, AES), WAPI
  • IEEE 802.11 priority control: WMM, WMM-PS
  • Integrated WiFi and BT antenna
  • Operation Temperature: -40oC to +85oC
  • Dimension: 40x16mm
  • Castellated pins: 52 pins. Easier prototyping, easier production.
  • Integrated shield to resist EMI

WZ662, Cortex A9+WiFi_BT module

  • Integrated WS662 with Toshiba TZ2102 processor to support high throughput  WiFi connection
  • Supports Ubuntu OS
  • Bluetooth 4.0 EDR + BLE stacks embedded in mask ROM
  • WiFi Access Point (AP) supports 5 clients with up to 30 Mbps throughput.
  • Cortex A9 processor, 600 MHz, 8GB eMMC and 512MB DDR3, Ubuntu OS.
  • IEEE 802.11 security: WEP, WPA/WPA2 (TRIP, AES), WAPI
  • IEEE 802.11 priority control: WMM, WMM-PS
  • Integrated WiFi and BT antenna
  • Operation Temperature: -25oC to +85oC
